SAJ CHS2 Series User Manual

CHS2 Series
15
16
Model
CHS2-29.9K-T4-X
CHS2-30K-T4-X
CHS2-40K-T5-X
CHS2-50K-T6-X
CHS2-63K-T6-X
Max. Apparent Power [VA]
29999
33000
44000
55000
63000
Peak Output Apparent Power [VA]
29999
45000,5s
60000,5s
75000,5s
75000,5s
Rated AC Voltage [V]
3+N+PE/3+PE, 380/400
Rated Output Frequency/Range [Hz]
50,60/45～55,55～65
Output THDv (@ Linear Load)
<3%
Efficiency
Max. Efficiency
≥98.0%
Euro Efficiency
97.3%
Max. Battery to AC Efficiency
96.0%
Protection
PV String Current Monitoring
Integrated
PV Insulation Resistance Detection
Integrated
Residual Current Monitoring
Integrated
PV Reverse Polarity Protection
Integrated
Anti-islanding Protection
AFD
AC Overcurrent Protection
Integrated
AC Short Circuit Protection
Integrated
AC Overvoltage Protection
Integrated
DC switch
Integrated
DC Surge Protection
II
AC Surge Protection
II
AFCI
Integrated
RSD
Optional
General Parameters
Communication
Wi-Fi/Ethernet/CAN/RS485
Topology
Non-isolated
Operating Temperature Range
-30℃ to +50℃ (45℃ to 50℃ with derating)
Cooling Method
Air Conditioner
Ambient Humidity
0-100% Non-condensing
Altitude
2000m
Ingress Protection
IP55, IP66(Inverter)
Dimensions [H*W*D] [mm]
1980*988*1065
Weight [kg]
1050(57.3kWh)/1150(71.6kWh)/1250(85.9kWh)/1350(100.3kWh)
Warranty [Year]
5/10
Standard
VDE4105,IEC61727/62116,VDE0126,AS4777.2,
CEI 0 21,EN50549-1,G98,G99,C10-11,UNE217002,NBR16149/NBR16150
IEC62109-1/-2, NB/T32004-2018, EN61000-6-1,EN61000-6-2,EN61000-6-3, EN61000-6-4
Note: X=204.8V/280Ah/51.5kWh,256.0V/280Ah/64.4kWh,307.2V/280Ah/77.3kWh,358.4V/280Ah/90.2kWh
Battery
Model
CB2-57.3-HV5
CB2-71.6-HV5
CB2-85.9-HV5
CB2-100.3-HV5
Rated Energy [kWh]
57.3
71.6
85.9
100.3
Usable Energy [kWh]
51.5
64.4
77.3
90.2
Rated Capacity [Ah]
280
280
280
280
No. of Modules
4
5
6
7
Nominal Voltage [V]
204.8
256
307.2
358.4
Voltage Range [V]
179.2~230.4
224~288
268.8~345.6
313.6~403.2
Charge/Discharge Current [A]
140
140
140
140
Rated Power [kW]
28.6
35.6
42.9
50.1
Weight [kg]
960
1060
1160
1260
Dimension [mm]
1980*988*1065
Communication
CAN
Operating Temperature Range [℃]
-30~50
Cooling Method
Air Conditioner
Relative Humidity
5~95% (non-condensing)
Altitude [m]
2000
Ingress Protection
IP55
Mounting
Ground-Mounted
Control Module
CBC2-HV5
Dimension (H*W*D)[mm]
225*483*610
Weight [kg]
28
Battery Module
CBU2-14.33-HV5
Rated Energy [kWh]
14.33
Weight [kg]
115
Dimension [mm]
231*523*805
Applicable Standard
IEC62619-2017, UN38.3, IEC61000-6-2/4, IEC62477

SAJ CHS2 Series Specifications

General

Brand	SAJ
Model	CHS2 Series
Category	Storage
Language	English
