SAJ VM1000B User Manual

VM1000B
- 12 -
Figure 2-1-2 11kW-110kW outline dimension diagram
AC Drive Model
Overall Dimensions
Mounting Hole
Mounting
Hole
Diameter
H
W
D
D1
H1
W1
d
VM1000B-4T011GB/015PB
348
182
211
196
331
156
6
VM1000B-4T015GB/18R5PB
VM1000B-4T18R5GB/022PB
373
220
205
190
356
156
6
VM1000B-4T022GB/030PB
VM1000B-4T030G/037P
435
256
222
208
419
170
6
VM1000B-4T037G/045P
VM1000B-4T045G/055P
543
310
280
265
523
245
10
VM1000B-4T055G/075P
VM1000B-4T075G/093P
580
358
328
314
560
270
10
VM1000B-4T093G/110P
VM1000B-4T110G/132P
Table 2-1-2 11kW-110kW outline dimension
