Chapter 4 Parameter function
“○”: the parameter can be modified in both standby and operating state；
“●”: the parameter can’t be modified in operating state；
“◎”:the parameter is the actual detected and recorded value which can’t be modified；
Note: the communication address is hexadecimal.
4.1 Functional parameter
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
F0 Group: basic function
F0.00
Motor control mode
0:Sensorless vector control（SVC）
1: V/F control
1
●
0000
F0.01
Command source
selection
0：Keypad control（LED off）
1：Terminal control（LED on）
2：Communication LED (LED blinking）
0
●
0001
F0.02
UP/DOWN standard
0：Operating frequency
1：Setting frequency
1
●
0002
F0.03
Setting main frequency
source X
0：Digital setting (non-retentive at power
failure)
1：Digital setting (retentive at power failure)
2：AI1
3：AI2
4：Reserved
5：Reserved
6：Multi-speed instructions
7：Simple PLC
8：PID
9：Communication setting
1
○
0003
F0.04
Setting auxiliary
frequency source Y
Same as F0.03(Settings of main frequency
source X)
0
○
0004
F0.05
Range of auxiliary
requency source Y
0：Relative to the maximum frequency
1：Relative to frequency source X
0
○
0005
F0.06
Percentage range of
auxiliary requency source
Y
0% ～ 150%
100%
○
0006
F0.07
Frequency reference
selection
Single-digit: Selection of frequency source
selection
0
○
0007
