SAJ VM1000B User Manual

VM1000B
- 20 -
3.2 Description of indicators and keys
Item
Name
Function
Indicator
Unit indicators
 Hz: Unit of frequency;
 A:Unit of current;
 V:Unit of voltage;
 RPM（Hz+A）: Unit of rotational speed;
 ％（A+V）: Percentage
Status
 RUN: ON/Running; OFF/Stop
 FWD/REV: ON/Forward rotation; OFF/Reverse
rotation; Blinking/Forward and reverse switching
 TUNE/TC: Blinking slowly/Auto-tuning state;
Blinking quickly/Fault state;
 LOCAL/REMOTE: ON/Terminal control；
Blinking/Communication; OFF/keypad control
Key
PRG
(Programming)
Enter or exit the first menu.
ENT (Confirm)
Enter the menu interfaces and confirm the parameter setting.
△（Increment）
Increase date or function code.
▽（Decrement）
Decrease data or function code.
>>（Shift）
Select the displayed parameters in the stop or running state
and select the digit to be modified when modifying
parameters.
RUN
Start the AC Drive in keypad control mode.
STOP/RESET
Stop the AC Drive when it is in the running state and perform
the reset operation when it is in the fault state. The functions
of this key are restricted in F7.02.
MF.K
(Multi-functional
choice)
Perform function switchover according to the setting of
F7.01.
Knob
Pulse
potentiometer
Can be used as frequency source.When used as a frequency
source, clockwise rotation increases the frequency and
counterclockwise rotation decreases the frequency.
Table 3-2-1 Description of Indicators and key
