SAJ VM1000B User Manual

VM1000B
- 22 -
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
0: main frequency source X
1. main and auxiliary operation results
2:Switchover between X and Y
3:Switchover between X and main (X) &
auxiliary(Y) operation
4:Switchover between Y and main (X) &
auxiliary(Y) operation
Ten’s digit：X and Y operation relationship
0：X+Y
1：X -Y
2：Maximum
3：Minimum
4：X*Y
F0.08
Keypad setting frequency
0.00Hz ～F0.10
50.00Hz
○
0008
F0.09
Running direction
selection
0：Same direction
1：Reveres direction
0
○
0009
F0.10
Maximum frequency
50.00Hz ～ 320.00Hz
50.00Hz
●
000A
F0.11
Source of frequency
upper limit
0：Set by F0.12
1：AI1
2：AI2
3：Reserved
4：Reserved
5：Communication setting
0
●
000B
F0.12
Frequency upper limit
Frequency lower limit (F0.14)～F0.10
50.00Hz
○
000C
F0.13
Upper limit frequency
offset
0.00Hz ～F0.10
0.00Hz
○
000D
F0.14
Frequency lower limit
0.00Hz ～F0.12
0.00Hz
○
000E
F0.15
The function of frequency
lower limit
0：Running at frequency lower limit
1：Stop
2：Standby
0
○
000F
F0.16
Carrier frequency
0.5kHz ～ 16.0kHz
Model
dependent
○
0010
F0.17
Reserved
-
-
-
0011
F0.18
Acceleration time 1
0.0s ～ 6500.0s
Model
dependent
○
0012
F0.19
Deceleration time 1
0.0s ～ 6500.0s
Model
dependent
○
0013
F0.20
Default setting restoring
0：No operation
1：Restore to factory default setting (not
including F2 parameters )
2：clear fault record
0
●
0014
