Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
6: Reserved
7: AI1
8: AI2
9: Reserved
10: Length
11: Count vaule
12: Communication setting
13: Motor rotational speed
14: Output current (0-1000A corresponding to 0-
10V)
15: Output voltage (0-1000V corresponding to 0-
10V)
16: DC bus voltage (0-1000V corresponding to
0-10V)
F6.14
Reserved
-
-
○
060E
F6.15
AO1 offset coefficient
-100.0% ～ 100.0%
0.00%
○
060F
F6.16
AO1 gain
-10.00 ～ 10.00
1
○
0610
F6.17
AO2 offset coefficient
-100.0% ～ 100.0%
0.00%
○
0611
F6.18
AO2 gain
-10.00 ～ 10.00
1
○
0612
F6.19
FMR connectting delay
time
0.0s ～ 3600.0s
0.0s
○
0613
F6.20
Relay 1 connectting delay
time
0.0s ～ 3600.0s
0.0s
○
0614
F6.21
Relay 2 connectting delay
time
0.0s ～ 3600.0s
0.0s
○
0615
F6.22
VDO connectting delay
time
0.0s ～ 3600.0s
0.0s
○
0616
F6.23
FMR disconnecting delay
0.0s ～ 3600.0s
0.0s
○
0617
F6.24
Relay 1 disconnecting
delay time.
0.0s ～ 3600.0s
0.0s
○
0618
F6.25
Relay 2 disconnecting
delay time
0.0s ～ 3600.0s
0.0s
○
0619
F6.26
VDO disconnecting delay
time
0.0s ～ 3600.0s
0.0s
○
061A
F6.27
Output terminal valid
state selection
0: Positive logic
1: Negative logic
Single digit: FDOR
Ten’s digit: RELAY1
Hundred’s digit: RELAY2
Thousand’s digit: Reserved
Ten thousand’s digit: Reserved
0
○
061B
F6.28
User defined output
0: Running frequency
0
○
061C
