4.2 Detailed Function Description
This function code defines the maximum
output voltage of VFD. When output feedback
disconnection happens and voltage increases
without control and lost protection, this
function can limit the output voltage within
the allowed range, which ensures the safe of
work load.
F5.24
limit voltage of voltage feedback
disconnection
0.0 ～ 100.0％ * motor rated
voltage
80.0%
0: speed command (output frequency,
-100.0% ～ 100.0%)
1: torque command (output torque,
-200.0% ～ 200.0%)
AI1 analog setting value works as torque
command value, given torque range is
-200.0% ～ 200.0%. Relevant setting see F6
group function code description.
2: voltage command (output voltage,
0.0% ～ 200.0%*motor rated voltage)
F6 analog and impulse parameters of input
and output
F6.00
AI1 input corresponding physical
quantity
0～2 0
0: speed command (output frequency,
-100.0% ～ 100.0%)
1: torque command (output torque,
-200.0% ～ 200.0%)
AI1 analog setting value works as given
value of torque command, which ranges
-200.0% ～ 200.0%. For relevant setting see
F6 group function code description.
2: voltage command (output voltage,
0.0% ～ 200.0%*motor rated voltage)
F6.01
AI1 input lower limit
0.00 ～ 10.00V/20.00mA 0.00
F6.02
AI1 lower limit corresponding physical
quantity setting
-200.0% ～ 200.0% 0.0%
F6.03
AI1 input upper limit
0.00 ～ 10.00V/20.00mA 10.00
F6.04
AI1 upper limit corresponding
physical quantity setting
-200.0% ～ 200.0% 100.0%
F6.05
AI1 input 󽗉ltering time
0.00S ～ 10.00s 0.05
F6.06
AI2 input corresponding physical
quantity
0～2 0
After voltage feedback disconnection, the
duration time before protection action.
F5.23
Detection time of voltage feedback
disconnection
0. 0 ～ 100.0s 10.0
The maximum value of specified voltage
works as the upper limit of feedback
disconnection detection value. Within the
time of feedback disconnection detection,
when voltage feedback value is continuously
lower than feedback disconnection detection
value, VFD will respond with protection action
according to F5.21 setting.
F5.22
Detection value of voltage feedback
disconnection
0.0 ～ 100.0％ *motor rated
voltage
2.0%
