3.8 Function Code Setting
The function parameter system of this inverter includes function code F0 ～ FF, fault code E group
and monitoring code D group. Each function group is consisted of several function code, which is
marked as (function group code + function code).
For example, "F5.08" means eighth function code in the 󽗉fth function group.
Function code setting example:
Example 1: change frequency setting of forward jogging form 5Hz to 10Hz (F1.20 modi󽗉ed from
5.00Hz to 10.00Hz)
Press key to enter programming status, LED displays function code F0.00, 󽗊icker bit stays
in the ones digit.
Press key, move the 󽗊icker bit among the hundreds place, tens place and ones place.
Press key or key to modify the digit in the according digit place. LED displays F1.20.
Press key, it displays the according value (5.00) of F1.20, meanwhile the indicator light
of unit Hz is on.
Press key, move the 󽗊icker bit to the highest place "5", press / key 5 times
to change it to 10.00.
Press key, save the value of F1.20 and displays next function code F1.21.
Press key, escape from programming status.
PRG
PRG
▲
▲
▼
▼
ENTER
ENTER
Example 3 : check fault monitoring parameter in fault status
Under fault status press key and check D group monitoring parameter ranging from D-00
to D-57.
If the fault wasn't eliminated during checking the fault parameter, the interface will
automatically switch to fault alarm display 5s later after stopping operation.
The fault code displays ranging from D-48 to D-57 (the current status and latest 3 times).
PRG
①
①
②
②
Method 2:
Under monitoring mode interface, press key, switch to next monitoring parameter item d-xx,
press key to move 󽗊icker bit to ones digit of the monitoring code, then adjust Key
or key until the monitoring code displays d-05, then operate according to step 2 and step 3
of method 1.
▲
▼
ENTER
③
③
④
⑤
⑥
⑦
