1.3 Technical Index and Specication
Typical
function
Multi-velocity
and Traverse
Operation
16 segments programmable multi-velocity control, multiple
operation mode. Traverse operation: preset frequency
and center frequency adjustable, parameter memory and
recovery after power cut.
PID Control
R5485
Communication
Built-in PID controller (able to preset frequency). Standard
conguration RS485 communication function, multiple
communication protocol for choice, synchronizing control
function.
Frequency
Setting
Analog Input
Direct voltage 0 ～ 10V, direct current 0 ～ 20mA
(optional up limit and lower limit)
Digital Input
Operation panel setting, RS485 port setting,
UP/DW terminal control, or combined with
analog input
Output Signal
Digital Input
2 channel OC output and one channel relay
output (TA, TB, TC), up to 16 choices
Analog Input
2 channel analog signal output, output
ranging within 0 ～ 20mA or 0 ～ 10V with
exibly setting, achievable output of physical
quantities like set frequency, output frequency
Automatic
Steady-voltage
Operation
Dynamic steady state, static steady state, and unsteady
voltage for choices to obtain the steadiest operation
Acceleration
and Deceleration
Time Setting
0.1s ～ 3600min continuous setting, S type and linear type
mode for choice
Brake
Dynamic
Braking
Dynamic braking initial voltage, backlash voltage and
dynamic braking continuous adjustable
DC
Braking
Halt DC braking initial frequency: 0.00 ～ [F0.16] upper limit
frequency
Braking time: 0.0 ～ 100.0s;
Braking current: 0.0% ～ 150.0% of rated current
Flux
Restraint
0 ～ 100 0: invalid
