091
F4.22
torque detection action
0～8 0
F4.23
torque detection level
G type: 150.0%
0.0％～ 200.0％ *rated
current of motor
P type: 110.0%
0.0％～ 200.0％ *rated
current of motor
Depending
on model
F4.24
torque detection time
0.0 ～ 10.0s 0.0
F4.15
Speed limit channel selection 2 of
torque control mode ( reverse)
0～2 0
This function code is used to set reverse speed
limit channel of torque control.
0: keypad number setting 2
See F4.17 setting.
1: AI1
Reverse speed limit channel is given by
AI1 in torque control. See function code
F6.00 ～ F6.05 description.
2: AI2
Reverse speed limit channel is given by
AI2 in torque control. See function code
F6.06 ～ F6.11 description.
Keypad limit speed 2 is relative to the value
of maximum output frequency. This function
code corresponds to reverse speed limit value
when F4.15=0.
F4.17
Keypad limit speed 2
0.0 ～ 100.0%*【F0.15】
max. freq.
100.0%
F4.16
Keypad limit speed 1
0.0 ～ 100.0%*【F0.15】
max. freq.
100.0%
Keypad limit speed 1 is relative to the value
of maximum output frequency. This function
code corresponds to forward speed limit value
when F4.14=0.
F4.18
Torque rise time
0.0 ～ 10.0s 0.1
F4.19
Torque decline time
0.0 ～ 10.0s 0.1
Torque rise/decline time defines the time of
torque rising from 0 to maximum value and
falling from maximum value to 0.
F4.20
motoring torque limit of vector mode
G type: 180.0%
0.0 % ～ 200.0% * rated
current of motor
P type: 120.0%
0.0% ～ 200.0%*rated
current of motor
Depending
on model
F4.21
brake torque limit of vector mode
G type: 180.0%
0.0 % ～ 200.0% * rated
current of motor
P type: 120.0%
0.0% ～ 200.0%*rated
current of motor
Depending
on model
These above function codes defined the
torque limit value of vector control.
4.2 Detailed Function Description
1: AI1
Forward speed limit channel is given by
AI1 in torque control. See function code
F6.00 ～ F6.05.
2: AI2
Forward speed limit channel is given by
AI2 in torque control. See function code
F6.06 ～ F6.11 description.
