CUSTOMIZATION OF SETTINGS
3.8 Revised 3/30/2010
Explanation of Sub Menu Items
This section explains the operations available from
the sub menu screen and how to change each setting
(Figure 3-T).
When the MENU key is pressed, the menu screen
appears. When the MENU key is pressed again, the
display switches to the sub menu screen.
The coverslipping performance of this system
changes according to the various conditions such as the
thickness of glass slide, whether or not the slide is coated,
characteristics of mounting medium, tissue type, and
temperature/humidity. So that coverslipping is performed
properly, the set values of coverslipping conditions used
by the system must be changed according to each
situation.
The sub menu provides an adjustment menu for
achieving optimal coverslipping when the present
condition of coverslipping is not favorable.
Press the MENU key to open then menu screen, and
then press the MENU key again to move to the sub menu
screen.
Highlight a desired item using the < and > keys, and
make the selection using the ENTER key.
Figure 3-T
1. SLOWDOWN POSITION- This function changes the
pressure applied when the cover glass is placed on
the slide. Use this menu item mainly when air bubbles
are present or mounting medium is seeping out
around the slide. See page 3.9.
2. COVER GLASS ANGLE- This function changes the
separation angle when a cover glass is picked up.
Use this menu item when more than one cover glass
is picked up or when cover glasses present cracks.
Select one of three values. If the cover glass brand is
changed, the value may need to be changed. See
page 3.10.
3. PICK UP SPEED- This function changes the speed at
which the glass slide is picked up. When the glass
slide pickup speed is changed, the amount of xylene
remaining on the slide at the time of pickup will
change. Use this menu item mainly when air bubbles
are present or mounting medium is seeping out from
the slides. If the solvent type is changed, this value
may need to be changed. See page 3.11.
4. DISPENSE POINT- This function changes the
position at which to start dispensing mounting
medium onto the glass slide, in a front to back
direction. Use this menu item mainly when air bubbles
are present on the front side of the slide or mounting
medium is seeping out from the sides. See page
3.12.
5. FIRST DISPENSE- This function adjusts the volume
of mounting medium to be dispensed at the dispense
point. The default value is 20 µL. Use this menu item
mainly when air bubbles are present on the front side
of the slide or mounting medium is seeping out from
the sides. See page 3.13.
6. DRYING FAN TIMER- This function changes the
receiving racks drying time in the unloading area after
completion of coverslipping. End of drying will be
signaled by an audible alarm. The default is 2
minutes. See page 3.13.
