ENGLISH
11
S170 Ø54
S201S220 Ø57
S161 Ø63
S230 Ø72
S150 72x50
5.2.3 DIRECTION OFROTATION
Serious damage can result if the pump is started or run in the
wrongdirectionofrotation.
Ensurethatthedirection of rotation is correctbeforefirst start‐up or if
maintenanceworkhasbeencarriedoutontheelectricpowersupply.
Direction of rotation must correspond to the arrow attached or
engravedinthepu
mp.
Check direction of rotation when motor is apart (coupling spacer
dismantledormotornotcoupledtopump).Ifnotfeasibleduetopump
design (pump fitted with rigid coupling) it is necessary to check that
pumpshaftturnsfreelyafterthetestandbeforefinalpumpstart.
Toch
eckdirectionofrotationstart motorbriefly and checkdirection of
rotation just before rotation stops. If direction of rotation must be
modifiedthenreversetwophasesinmotorjunctionbox.
Itispossibletochangetwophasesinthecontrolcabinetonmotor
starter connections. If this solution is preferr
ed then it will be
necessary to modi fy the identification of the cables in the electrical
drawingstoo.
5.2.4 NOISELEVEL
Noiselevel of a completepumpset depends onmotortype and speed,
onqualityandwearofflexiblecoupling(if concerned),onfluidvelocity,
pipingdesign,…Valuesgivenhereafterareonlyindicativeandbasedon
fancooledelectricmotorsaveragenoiselevels.
The test must be performed on the supplied pump if the noise
levelmustbecert
ified.
Ifnoiselevelishigherthan85dBA,personelworkinginpumparea
shouldwearhearingprotections.
Pumpsize
Speed
(RPM)
For
maximum
flow[dB]
Atbest
efficiencyoint
[dB]
Atzeroflow
[dB]
S40 2900 71 66 79
S41 2900 66 62 73
S45 2900 71 68 69
S46 2900 66 65 68
S50 2900 75 69 72
S51 2900 68 66 69
S60 2900 72 71 73
S61 2900 67 67 74
S63 S2900 85 79 80
S65 1450 64 62 68
S68 2900 87 79 83
S80(‐2) 2900 85 72 74
S80K 2900 79 73 76
S83 2900 89 78 86
S85 1450 68 65 72
S88 2900 94 87 89
S88(210) 2900 90 83 84
S100 2900 88 81 98
S105 1450 83 67 73
S108 2900 86 84 84
S120 1450 78 74 78
S150 1450 84 74 89
S160 1450 81 75 80
S170 950 83 76 77
IndicativenoiselevelgivenindBA(LpAat1m)
5.2.5 CONNECTIONS
Suctionflangeaxisishorizontalandthefaceisvertical.
Dischargeflangeaxisisverticalandthefaceishorizontal.
5.2.6 PERMISSIBLEFORCES ANDMOMENTS
No other stress than the one due to fastening of pipe and pump
flangestogethershouldapply.Nostressmustbeapplied topump
casing by the pipe work. A pre‐stress may exceptionally be applied to
flanges to compensate a pipe expansion. But in any case the resulting
forcesshouldnotexceedvaluesgivenhereafter:
DN
F
(x,y,z)
(N)
M
t(x,y,z)
(Nm)
1’’1/2‐40 415 208
2’’‐50 520 264
3’’‐80 520 264
4’’‐100 832 416
6’’‐150 1040 528
8’’‐200 1220 670
Appliedforcesandmomentsshouldnotbemaximumatthesame
time.
5.2.7 SCOPE OF DELIVERY
Pump can be delivered as a complete pump set including electrical
motor, flexible coupling, coupling guard and baseplate. It can be also
deliveredwithoutoneofthoseparts. ACEintegrationcertificateisthen
supplied.
This instructionsand operating manual is part of the pump supply and
should be delivered attached to the pump. If not, ask SALMS
ON
Customerdepartmenttogetit.
ATEXpumpsmaybedeliveredwithspecificinstrumentation.Refer
to pump technical datasheet or to acknowledgment of order to
knowexhaustivescopeofsupply.
6 DESCRIPTIONANDWORKINGPRINCIPLE
6.1 PRODUCTINFORMATION
S pump is a single stage self priming pump. Several variants of
construction are available: close‐coupled (without shaft coupling),
Biblockorwithballbearingsassemblyfittedwithelasticcoupling.
Close‐coupled pumps use a long shaft electric motor. Biblock pumps
accept flanged normalized IEC motor. Other pumps sets use IEC B3
mot
ors. Diesel or gasoline engines can be used for mobile or fixed
installations.
S pumps include an open impeller, wear plate(s) (rear and front wear
plates according to pump size), single mechanical seal and non‐return
valveintegratedinthesuctionflangeassembly.
Zinc anodes or internal coating with Ce
ram C0 can be supplied as an
optionforspecificapplications.
