PRODUCT SPECIFICATION
Model: EP101
Type: Programmable heating controller
designed for 230V AC and Volt Free
heating applications.
Programming
Programming Modes: User selectable for 5/2 or 7 day option
Number of Programmes: Three (3) user programmes plus
factory default programme.
Override Facility: User selectable programme
override facility.
Holiday Facility: User selectable option to temporarily
override selected programme.
Default Programmes
Programme Output Weekday Weekend
1 ON 6:00 AM 6:00 AM
OFF 8:00 AM 8:00 AM
2 ON 10:00 AM 10:00 AM
OFF 12:00 PM 12:00 PM
3 ON 6:00 PM 6:00 PM
OFF 10:00 PM 10:00 PM
Switching
Switching Voltage: 230V AC / 50Hz
Switching Current: 16A resistive, 5A inductive
Contact Type: Single Pole Double Throw (SPDT)
Environment
Operating Temperature: 0 ºC to + 50 ºC
Storage Temperature: - 20 ºC to + 60 ºC
EP101 INSTRUCTION MANUAL
21
