JUMPER SETTINGS
Changes to the jumper settings should only be made by the Engineer
carrying out the installation or other qualified person.
The installer should select the jumper positions required if changes need to
be made to the factory default settings. These jumpers are found on the
rear of the controller.
Jumper Function Default
Program Type Movable jumper for 5-2 or 7 5-2
individual days programming. programming
Internal Movable jumper for Internal backup
Backup Battery enabling or disabling the battery disabled
internal backup battery.
The installer should enable the internal backup battery before fitting the
controller to ensure user settings are retained – the battery will be kept
charged from the controller mains supply.
EP101 INSTRUCTION MANUAL
7
