Reset Function
The Reset Button is provided as a way to restore the programmable thermostat to its default factory settings.
Pressing this button will delete any previously entered settings. This should only be done by your installer.
RESET
+Hr
SELECT SET
Press the Reset button once.
You can use a paper clip.
Your device is now reset
to factory settings.
RESET
+Hr
SELECT SET
Model RT510
Type Electronic programmable thermostat, designed for Volt Free and AC
heating applications
Programming Modes User selectable for 5/2 and 24hr options
Program Number 1-6 Selectable
Modes Holiday, Boost, Program and Frost
Override Permanent and temporary
Frost Protection 5ºC Adjustable
Power Source 2xAA Alkaline Batteries
Temperature Scale 5 to 35ºC,
Device Parameters See page 9
Operating Temperature 0 to 40ºC
Storage Temperature -20 to 60ºC
Technical Information
1 2
20 RT510 Installation Manual
