Module 5 – Connected Fan Coil Controls
ST101ZB Low Voltage Fan Coil Thermostat
Section 4
Step 3. Attach Thermostat to the Wiring Mount
by aligning the connector pins.
Make sure the connector pins are not bent and that the Thermostat is fully seated on the
wiring mount.
Step 4. Turn on power to the fan coil system
and thermostat.
