Module 5 – Connected Fan Coil Controls
Parameter List
Appendix A
P Name Values Default Description/Comment
P00 Type of thermostat
0 = Non-Programmable
1 = Programmable
0
P01 Fan Coil Type
0 = 2 Pipe
1 = 4 pipe
1
P02 Heat/Cool Option
For 2 Pipe
3
Option #3 & #4 in the 2 pipe
configuration require the pipe
sensor (sold separately) to be
connected
0=Heat Only
1=Cool Only
2 = Heat or Cool Manual changeover
3 = Heat or Cool Seasonal changeover
4 = Heat or Cool with Auxiliary Heat
For 4 Pipe:
2 = Heat or Cool Manual changeover
3 = Heat, Cool or Auto changeover
4 = Auto changeover only
P03 Valve Type
0 = Normally Closed Valve
1 = Normally Open Valve
0
P04 Max. heating setpoint 41 to 92°F (5 to 33.5°C)
92°F
(33.5°C)
Not displayed if P02 = 1
P05 < P04
P04 ≤ P06-1.5°C
P05 Min. heating setpoint 41 to 92°F (5 to 33.5°C)
41°F
(5°C)
Not displayed if P02 = 1
P05 < P04
P05 ≤ P07-1.5°C
P06 Max. cooling setpoint 44 to 95°F (6.5 to 35°C)
95°F
(35°C)
Not displayed if P02 = 0
P07 < P06
P06 ≥ P04+1.5°C
P07 Min. cooling setpoint 44 to 95°F (6.5 to 35°C)
44°F
(6.5°C)
Not displayed if P02=0
P07 < P06
P07 ≥ P05+1.5°C
P08
Protection heating
setpoint
OFF or 41 to 92°F
(OFF or 5 to 33.5°C)
41°F
(5°C)
If not OFF, P05 < P08 < P04
P08 < P09
P09
Protection cooling
setpoint
OFF or 44 to 95°F
(OFF or 6.5 to 35°C)
OFF
If not OFF, P07 < P09 < P06
P08 < P09
P10
Offset of internal
sensor
±6°F - 1°F increments
(±3°C - 0.5°C increments)
0°F
(0°C)
To change parameters, press and hold the MODE, , keys simultaneously.
Use the and keys to scroll to “49” and press SELECT.
To Next Page
