ST103ZB Wireless Fan Coil Remote Installation
The ST103ZB Wireless Fan Coil Remote acts as a remote thermostat which can be wall mounted
or placed in a stand for desk or cabinet top operation. The Wireless Remote can be paired prior to
mounting (see Section 5, Pairing Instructions for details). For desk top operation, the ST103ZB can
be moved to a dierent location at any time.
Wall Plate Mounting
Desk or Cabinet Top Mounting
Remove the Wall Mount
from the back of the
ST103ZB Wireless Fan Coil
Remote.
Attach the Wall Mount in
the desired location using
the screws and anchors
provided.
Slip the ST103ZB Wireless
Fan Coil Remote onto the
Wall Mount.
Remove the Wall Mount from the back
of the ST103ZB Wireless Fan Coil Remote.
Slip the ST103ZB Wireless Fan Coil
Remote onto the Desk Stand.
