6-1
Section 6
SC102ZB/ST103ZB Installation and Operation Manual
Device Controls – Keypad & Display
Keypad
MODE
Heat, Cool, Auto, Off selection Increase Value
Fan On/Auto, Low Speed, Medium
Speed, or High Speed
Decrease Value
Enter/Exit Settings mode
SELECT
Confirm/Change Display Mode/Acti-
vate Permanent Hold
Display Icons
SC102ZB
ST103ZB
Table 6.1: Keypad Functions
SC102ZB ST103ZB
