SAMES KREMLIN 20F50 - Page 109

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020
109
 Remove the seal (35).
 Clean the parts.
 Replace the seal (35), grease it (PTFE grease) and
reinstall it on the exhaust valve (34).
 Place the ball (32) on the exhaust valve (34).
 Apply adhesive (Loctite 5772) to the piston thread
(24).
 Place the exhaust valve (34) and screw it on manually
at the contact.
Tools needed
34
35
PTFE grease
34
32
Loctite 5772
