SAMES KREMLIN 20F50 - Presentation of the Material; Complete System

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020
21
5 Presentation of the material
5.1 Complete system
5.1.1 Visual generic presentation
(Non-contractual visual)
Ind Description Ind Description
A Pump (B + C) J Discharge valve
B Air motor L Suction rod
C Fluid section M Fluid filter
D ‘AIR MOTOR’ air regulator N Drain valve
E Gauge O Drain rod
F ‘GUN AIR’ air regulator P HP fluid hose
G Gauge Q Spray gun
H Air inlet valve T Air hose (static conductor)
I Ground
C
D
E
H
J
L
P
O
N
M
B
T
Q
F
G
I
