 Manually insert the piston assembly (43), piston rod
(17) against nut (21), driving rod (15) and piston nut
(42) into the cylinder (40).
 Manually insert the cylinder assembly (40) piston (43),
piston rod (17) against nut (21), driving rod (15) and
piston nut (42) on the lower flange (3).
43
17
21
15
40
3
