20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
160
Common parts
Ind # Part numbers Description Qty
*6 144 579 912 Gasket seal (x 10) 1
*7 046 170 508 Base, fixed 1
*8 044 570 324 Base, mobile 1
9 044 570 325 Pin 1
10 921 140 102 Spring 1
11 044 571 006 Stop, spring 1
*12 144 579 922 Ring, R 10 (x 10) 3
*13 144 579 911 Pin (package of 10 pins
+ 1 stop ind. 11)
1
*14 144 579 910 Ring, R 6a (x 10) 1
*15 NS Seal, cover 1
16 144 630 415 Cover 1
17 933 151 277 Screw, SHC M 6x20 (x 1) 4
18 906 333 102 Plug, 1/4 BSP 1
19 046 170 510 Lever, control 1
Ind # Part numbers Description Qty
* 146 270 950 Package of seals
(ind. 6, 12 (x 3), 14, 15)
1
* 144 630 425 Servicing kit - bases
(ind. 7, 8)
1
* Preceding the index number denotes a suggested spare parts.
N S: Denotes parts are not serviceable.
