582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020
163
Ind # Part numbers Description Qty
1 044 970 451 Suction flange 1
2 044 970 052 Cylinder 1
3 044 970 060 Coupling rod (x 1) 4
4 953 010 021 Nut, HM 10 (x 1) 4
5 963 040 021 Washer, MU 10 (x 1) 4
6 044 970 445 Suction bearing 1
7 044 970 046 Flange, bellows 1
*8 044 970 055 Bellows 1
9 933 151 526 Screw, SHC M 8 x 45 (x 1) 4
10 044 970 047 Skirt 1
11 044 970 049 Intermediate piston 1
12 050 040 323 Seal, PTFE (x 1) 2
13 930 151 598 Screw, SHC M 6 x 60 (x 1) 3
14 931 151 168 Screw, SHC 5 x 12 (x 1) 4
* Preceding the index number denotes a suggested spare parts.
