Ind # Part numbers Description Qty
* 144 951 090 Package of seals 1
12 050 040 323  Seal, PTFE (x 1) 3
23 050 040 317  Seal, PTFE 1
32 NS  Ball, ceramics Ø 9,525 1
35 909 150 245  Rod seal, GT 1
36 144 970 106  Seal (x 10) 1
39 907 414 703  Ball, ceramics Ø 16 1
40 044 550 029  Rush 1
42 050 040 318  O-Ring, PTFE 1
43 909 150 244  Piston seal, GT 1
44 129 489 902  Seal, PTFE (x 10) 1
45 150 040 321  Seal, PTFE (x 10) 1
* Preceding the index number denotes a suggested spare parts.
N S: Denotes parts are not serviceable.
How to assemble the seals
