SAMES KREMLIN 20F50 - Page 69

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020
69
 Place the washers (5).
 Screw on the 4 nuts (4) using a 17 mm socket wrench.
 Place the ball (32) on the exhaust valve seat (34).
 Apply adhesive (Loctite 5772) to the piston thread (24).
 Position the exhaust valve (34) and screw it on
manually at the contact.
Tools needed
4
5
34
32
24
Loctite 5772
17
