 Tighten the skirt (10) by holding it with a 36 mm open-
end wrench and tightening the intermediate
piston(11) with an 11 mm open-end wrench.
 Screw in the 3 M 6 x 60 (13) SHC screws (13) using a 5
mm Allen wrench.
Tools needed
11
10
11
13
5
