SAMES KREMLIN 20F50 - Page 91

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020
91
 Place the ball (32) on the exhaust valve seat (34).
 Apply adhesive (Loctite 5772) to the piston thread
(24).
 Place the exhaust valve (34) and screw it on manually
at the contact.
 Hold the piston with a 16 mm open-end wrench and
tighten the exhaust valve (34) with an 18 mm open-
end wrench.
Tools needed
34
32
24
Loctite 5772
34
18
16
