SAMES KREMLIN 20F50 - Page 99

582156110-EN-indC-Pump-20F50 pH.docx 20/11/2020
99
 Unscrew the suction valve (50) with a 41 mm wrench.
 Remove the gasket (42) with a flat screwdriver.
 Remove the locking ring (40) with a flat screwdriver.
 Remove the ball (39).
 Clean the parts, change the gasket (42) and
reassemble the ball (39) and the retaining ring (40).
Tools needed
50
41
