3.9 SIZING OF AC OUTPUT WIRING AND BREAKERS
3.9.1 EVO-1212F and EVO-1224F
120 VAC output is supplied through NEMA5-15 Duplex GFCI Outlets (15, Fig 2.1). The outlets are protected against
over current through 15A Circuit Breaker (14, Fig 2.1).
Use power cord with NEMA5-15 plug and conductor size AWG #14.
3.9.2 EVO-1212F-HW and EVO-1224F-HW
WARNING!
For EVO-1212F-HW and EVO-1224F-HW, AC Breakers for the AC output circuits have NOT been provided
internally. These have to be provided externally by the installer / user based on guidelines given below.
Please note that guidelines given below on wire sizing and over-current protection will be superseded by the
applicable National / Local Electrical Codes.
MISE EN GARDE!
Pour EVO-1212F-HW and EVO-1224F-HW breakers AC pour les circuits d’entrée AC ont pas été fournis
en interne. Ceux-ci doivent être fournies à l’extérieur par l’installateur / utilisateur sur la base des
directives données ci-dessous. Se il vous plaît noter que les directives ci-dessous sur dimensionnement
des câbles et protection contre les surintensités seront remplacées par les nationaux / codes électriques
locaux applicables.
Table 3.3 provides details of wire and breaker sizing for the AC output side for EVO-1212F-HW and EVO-1224F-HW.
AC wiring and breaker sizes on the AC output side are required to be determined by the Rated Load Current when
operating in Inverter Mode (Column 1).
TABLE 3.3 SIZING OF AC OUTPUT WIRING AND BREAKERS
Model No. and Rated
Output Power in
Inverter Mode
(Column 1)
Rated AC Output
Current in Inverter
Mode
(See Note 2)
(Column 2)
NEC Ampacity =
125% of Column 2
(See Note 3)
(Column 3)
Conductor Size based
on NEC Ampacity at
Column 3
(See Note 4)
(Column 4)
Size of Breaker
(Column 5)
EVO-1212F-HW
(1200VA)
10A 12.5A AWG #14 15A
EVO-1224F-HW
(1200VA)
10A 12.5A AWG #14 15A
