Samlexpower Evolution Series - Specifications

SAMLEX AMERICA INC. | 127
SECTION 7 | Specications
Models
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
INVERTER SECTION
Output Waveform Pure Sine Wave
Input Battery Voltage Range 9.1 - 17 VDC 18.1 - 34 VDC
Nominal AC Output Voltage 120 VAC ± 5%; Single Phase
Output Frequency 60 Hz ± 0.1 Hz
Total Harmonic Distortion of Pure
Sine Wave Form (THD)
< 5%
Continuous Output Power and
Power Factor (PF)
1200 Watt at PF = 0.95
Continuous AC Output Current 10A
Surge Power for 1 msec
300%
(3600VA, 30A)
Surge Power for 100 msec
200%
(2400VA, 20A)
Power Boost for 30 sec
150%
(1800W at PF = 0.95)
Power Boost for 1 min
140%
(1680W at PF = 0.95)
Power Boost for 10 min
120%
(1440W at PF = 0.95)
Power Boost for 30 min
110%
(1320W at PF = 0.95)
Maximum Continuous DC Input Cur-
rent
152A 76A
Inverter Efciency (Peak)
89% 91%
No Load Power Consumption in
Power Saving Mode
< 8 W
No Load Power Consumption in
Normal Mode (120 VAC Output,
Typical)
20 watts 20 watts
No load Power Consumption in
Standby Mode
(Inverting/ Charging are suspended)
< 5W
AC INPUT
AC Input Voltage 120VAC (60-140VAC +/- 5% selectable)
AC Input Frequency 60Hz
Maximum Programmable AC Input
Current (GRID MAX CURRENT)
5 - 20A
(Default - 20A)
AC Input Breaker Size
20A
(i) EVO-1212F and EVO-1224F have built-in Breaker
(ii) For EVO-1212F-HW and EVO-1224F-HW, breaker
has to be installed externally by the installer / user.
