128 | SAMLEX AMERICA INC.
SECTION 7 | Specications
Models
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
TRANSFER CHARACTERISTICS
Transfer Relay Type and Capacity
SPDT, 40A
NOTE: In Charging Mode, input current is limited to 20A by input breaker and
pass through current to the AC load is limited to 15A by the output breaker
Transfer Time – Inverter to Grid /
Generator
< 1 ms (Synchronized transfer at zero crossing)
Transfer Time – Grid / Generator to
Inverter
Up to 18ms (Synchronized transfer at zero crossing)
INTERNAL BATTERY CHARGER SECTION
AC Input Voltage Range
120 VAC (60 to 140 VAC +/-5% selectable) ; 60 Hz ; Single Phase
Rated Continuous AC Input Current
11.2A, AC
(At BULK CURRENT = 60 ADC)
11.2A, AC
(At BULK CURRENT = 40 ADC)
AC Input Power Factor (PF)
> 0.95
Programmable Bulk Charging
Current
0 - 60A, DC 0 - 40A, DC
Programmable Charging Voltages :
Bulk / Absorption Stage
Float Stage
Equalization Stage
13.5 to 16.0V (Default 14.4V)
13.0 to 15.0V (Default 13.5V)
14.0 to 16.0V (Default 14.4V)
27.0 to 32.0V (Default 28.8V)
26.0V to 30.0V (Default 27.0V
28.0 to 32.0V (Default 28.8V)
Charger Efciency 75% 86%
Programmable Charging Proles
 3 proles under 3-Stage Charging: Bulk, Absorption, Float
 1 prole under 4-Stage Charging: Bulk, Absorption, Equalize, Float
 2 proles under 2-Stage Charging: Bulk, Absorption
Battery Temperature Compensation
 Battery Temperature Sensor EVO-BTCS included
 Compensation Range from -20° C to 60° C
EXTERNAL BATTERY CHARGER SECTION (Solar Charge Controller)
Charging Voltage Range 13 - 16 VDC 26 - 32 VDC
Maximum Charging Current 50A
COOLING, PROTECTIONS AND ALARMS
Cooling
2 Fans – Temperature Controlled, Variable Speed
Protections and Alarms
Battery Low Voltage Alarm and Low / Over Voltage Shut Down
Shut Down under Input Over Current, Output Over Current, Output Overload and
Output Short
Transformer and Heat Sink Overheat Shut Down
Immunity Against Conducted Electrical Transients in Vehicles
Built-in Over Current Breakers
Input: 20A
Output: 15A
 For EVO-1212F and EVO-1224F only.
 To be installed externally for EVO-1212F-HW
and EVO-1224F-HW
