SAMLEX AMERICA INC. | 129
SECTION 7 | Specications
Models
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
INPUT AND OUTPUT CONNECTIONS
Battery Connection  Stud and Nut: M8 (Pitch1.25mm)
External Charge Controller
Connection
 Stud and Thumb Nut: M6 (Pitch 1mm)
AC Input Connection
(i) EVO-1212F and EVO-1224F:
• IEC 60320 C-20 Male Power Inlet Plug. Requires 20A Detachable Power Cord
with mating IEC 60320 C-19 Socket Connector and NEMA5-20P Plug
(ii) EVO-1212F-HW and EVO-1224F-HW:
• Terminal Block
AC Output Connection
(i) EVO-1212F and EVO-1224F:
• NEMA5-15P, Duplex GFCI Outlet, 15A
(ii) EVO-1212F-HW and EVO-1224F-HW:
• Terminal Block
OPTIONAL REMOTE CONTROL
Model No.  EVO-RC-PLUS
Specications
 Advanced Features for programming various parameters and modes of operation
 4 Rows of 20 Character Alpha Numeric LCD Display for messaging
 Up to 16 GB SD Card Slot for Data Logging
 Comes with 10M / 33ft RJ-45 Data Cable
COMPLIANCE
Safety Compliance
 Intertek-ETL listed: Certied to CAN / CSA STD. C22.2 No. 107.1-01
 Intertek-ETL listed: Conforms to ANSI / UL STD. 458
EMI / EMC Compliance
 Certied to FCC Part 15(B), Class A
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
-20° C to +60° C (-4° F to 140° F)
Storage Temperature
-40° C to +70° C (-40° F to 158° F)
Operating Humidity
0 to 95% RH non condensing
WEIGHTS AND DIMENSIONS
Dimensions: W x D x H 324 x 415 x 148 mm; 12.76 x 16.34 x 5.83 in
Weights: 17.6 Kg / 38.8 lb 17.6 Kg / 38.8 lb
NOTES:
(1) All AC power ratings in the Inverter Section are specied at Power Factor = 0.95
(2) All specications given above are at ambient temperature of 25°C / 77°F unless specied otherwise
(3) Specications are subject to change without notice
