SAMLEX AMERICA INC. | 117
CAUTIONS!
a) Please ensure that all safety instructions at Section 1 of this manual are read and understood before
operating the unit
b) Please ensure that the unit has been installed properly as per instructions at Section 3 of this manual
ATTENTIONS!
a) Veuillez vous assurer que toutes les instructions de sécurité de la Section 1 de ce manuel sont lues et
comprises avant d’utiliser l’appareil.
b) Veuillez vous assurer que l'appareil a été installé correctement conformément aux instructions de la
section 3 de ce manuel.
INFO
Please ensure that charged battery has been connected to the DC Input Terminals (1 and 2 in Fig2.1). This
unit will NOT operate if specied battery voltage as shown below is not available at the DC Input terminals:
a) 12V units i.e. EVO-2212/3012……….. ≥ 9.1VDC
b) 24V units i.e. EVO-2224/4024……….. ≥ 18.1VDC
6.1 POWERING ON / POWERING OFF USING FRONT PANEL ON/OFF BUTTON (11, FIG 2.1)
INFO
For power on / power off sequence using EVO-RC-PLUS Remote Control, refer to Section 3.2 of EVO-RC-PLUS
Remote Control Manual.
6.1.1 Manual Power on Sequence when AC Input is in Switched Off condition / Not Connected:
To power ON the unit, press and hold the ON/OFF Button on the front panel (11, Fig 2.1) for around 3 seconds until
completion of sequence shown below:
• Blue LED marked “ON” (12, Fig 2.1) will blink 3 times, will go off momentarily and will then be steady Blue. Now,
release the ON/OFF Button. Subsequently, the lighting pattern of this LED will be controlled by various operating
conditions given in Table 6.1
NOTE: For Power on / off sequence when using the optional Remote Control EVO-RC-PLUS, please refer to Section 3.2
of EVO-RC-PLUS Remote Control Manual.
SECTION 6 | Operation, Protections and Troubleshooting
