When the Drain-Source terminals of the BMS close, Pins 1/2/3/4 and 5/6/7/8 of RJ-45 Jack will be shorted. The following
actions will be activated in EVO:
• EVO in Charging Mode: Charging will stop (Internally, the EVO will be in Charging Mode, but the charging
current will be reduced to 0A). Charging Mode Screens in EVO-RC-PLUS Remote Control will show message
"Charger Off by BMS" [Refer to display screens shown in Fig 3.7 under Section 3.6.8 of EVO-RC-PLUS Remote
Control Manual].
• EVO in Inverting Mode: Inverting will stop (Internally, the EVO will enter Standby Mode).Inverting Mode Screens
in EVO-RC-PLUS Remote Control will show message "Inverter Stop by BMS" [Refer to display screens shown in
Fig 3.8 under Section 3.6.9 of EVO-RC-PLUS Remote Control Manual].
5.12 OPERATING MODE OPTION - “CHARGER ONLY”
In Off-grid DC powered homes, for efciency consideration, all lighting and other loads / appliances are normally
powered from 12V batteries that are primarily charged through solar / wind power. Generator backup is used
for powering AC to DC battery charger for charging the batteries during extended periods of cloudy / no wind
conditions. To meet this requirement, the EVO
TM
can be programmed to operate as a battery charger ONLY i.e. when
AC input power is available within the programmed limits of voltage and frequency, charging will take place and AC
input will be passed through to the load(s). The unit will not transfer to Inverting Mode if AC input fails or is outside
the programmed limits of voltage and frequency. For further details refer to Section 4.4.2.13.1 in EVO-RC-PLUS
Remote Control Manual.
SECTION 5 | Battery Charging in Evolution™ Series
