• EVO in Charging Mode: The charging will stop (charging current will be reduced to 0A). The 2nd Line of the
Charging Mode Screens shown in the Menu Map for Charging Mode Screens (Fig 3.7 in EVO-RC Plus Manual)
will show “Charger Off by BMS” as shown in example below for Screen No. 1
Screen No.1
E V O - 1 2 1 2 F C h a r g i n g
C h a r g e r O f f b y B M S
B a t t e r y 1 2 . 0 0 V 0 . 0 A
E x t e r n a l 0 . 0 A
• EVO in Inverting Mode: Inverting will stop. EVO™ will go to Standby Mode. The right half of the 1st Line of
the Standby Mode Screens shown in the Menu Map for Standby Mode Screens (Fig 3.8 in EVO-RC Plus Manual)
will show “Inv stop by BMS” in 2 consecutive displays - rst “Inv stop” and then “by BMS” as shown in example
below:
Screen No.1 For 2 sec Screen No.1 For 2 sec
E V O - 1 2 1 2 F b y B M S
A C O u t p u t : 0 . 0 0 V
< 0 . 1 0 A
0 0 . 0 0 H z
E V O - 1 2 1 2 F I n v s t o p
A C O u t p u t : 0 . 0 0 V
< 0 . 1 0 A
0 0 . 0 0 H z
