8 | SAMLEX AMERICA INC.
TABLE 1.1.3 SIZING OF BATTERY SIDE CABLES AND EXTERNAL BATTERY SIDE FUSES
(Refer to Section 3.5.5, Table 3.1 for more details)
Model No.
(Column 1)
Rated
Continuous
DC Input
Current
(Column 2)
NEC
Ampacity
= 125% of
Rated DC
Input Current
at Column 2
(Column 3)
90°C Copper Conductor. Size Based on NEC Ampacity at
Column (3) or 2%Voltage Drop, whichever is Thicker
External
Fuse Based
on NEC
Ampacity at
Column (3)
(Column 9)
Cable Running Distance
between the Unit
and the Battery
(Cable Routing In Free Air)
Cable Running Distance
between the Unit
and the Battery
(Cable Routing In Raceway)
Up to 5 ft.
(Column 5)
Up to 10 ft.
(Column 6)
Up to 5 ft.
(Column 7)
Up to 10 ft.
(Column 8)
EVO-1212F
152 190 AWG #2 AWG #2/0 AWG #2/0 AWG #2/0 200A
EVO-1212F-HW
EVO-1224F
76 95 AWG #6 AWG #4 AWG #3 AWG #3 100A
EVO-1224F-HW
External Char-
ger
50A 63A
AWG #6
(2% voltage
drop is thicker)
AWG #2
(2% voltage
drop is thicker)
AWG #6
AWG #2
(2% voltage
drop is thicker)
70A
TABLE 1.1.4 TIGHTENING TORQUES
Battery Input Connectors External Charger Input Connectors AC Input and Output Connectors
70 kgf.cm
(5.0 lbf.ft)
35 kgf.cm
(2.5 lbf.ft)
7 to 12 kgf.cm
(0.5 to 0.9 lbf.ft)
TABLE 1.1.5 USE OF SPECIFIED GROUND FAULT CIRCUIT INTERRUPTER (GFCI) FOR DISTRIBUTION OF AC
OUTPUT POWER IN RECREATION VEHICLES
Manufacturer of GFCI Manufacturers’ Model No. Description
Jiaxing Shouxin Electric Technology Co. Ltd TS-15, TS-20
NEMA5-20, Duplex, 20A
NEMA5-15, Duplex, 15A
SECTION 1.1 | Safety Instructions
