5.7 3-STAGE CHARGING PROFILE - DETAILED EXPLANATION
Refer to 3 types of 3-Stage Charging Prole options at Srls. 1 to 3 in TABLE 5.2.
Fig. 5.1 shows the voltage and current charging curves with respect to time and different charging stages associated
with these proles.
i
INFO
4-Stage Adaptive Charging Prole for Equalization is also available and can be activated at any time during
charging taking place under these 3-stage proles. Procedure to activate 4-Stage Adaptive Charging Prole
for Equalization is described under programming parameter "EQUALIZE-4 STAGES" at Section 4.4.2.12 in
the EVO-RC-PLUS Remote Control Manual.
SECTION 5 | Battery Charging in Evolution™ Series
