Design and principle of operation
3.8 Technical data
Actuator Type3274 -13 -14 -17 -18 -21 -22 -23
Handwheel Electric Mechanical Electric
Fail-safe action Without Without With
Direction of action: stem re-
tracts
– – •
Direction of action: stem
extends
– – •
•
Rated travel 15or30mm
Transit time for rated travel 60swith15mmtravel·120swith30mmtravel
Faster motor
2)
:30swith15mmtravel·60swith30mmtravel
Strokingspeedinmm/s 0.25;fastermotor
1)
: 0.5
Strokingspeedforfail-safeactioninmm/s
Standard
— —
1 1 1.3
Optional 3.3 3.3 5
Weight 12kg 15kg 12kg
Supply voltage 230Vand24V,50or60Hz(±10%)
Power consumption with
supply voltage
24V,230V/50Hz:90VA
24V,230V/60Hz:110VA
230V/50Hzwithfastermotor:150VA
230V/60Hzwithfastermotor:185VA
Positioner:3VA
Perm. ambient temperature –10to+60°C
Perm. storage temperature –25to+70°C
Degree of protection IP65accordingtoEN60529
Electromagnetic
compatibility
AccordingtoEN61326-1,EN61000-6-2andEN61000-6-3
Conformity
·
1)
Notforactuatorswith24Vsupplyvoltage
