Samson 3274 - Adjusters and Slider Switches

EB 8340 EN 6-3
Operation
6.3 Adjusters and slider switches
Adjusters and slider switches are located underneath the side housing cover in the actuator
version with positioner.
on
off
1234
Zero
in
Span
out
Span
in
20
0
40
60
80
100
%
Startingpoint(zero) Upper range value (span)
Position feedback (output signal)
SW1
SW2
SW3
SW4
Adjusters Slider switch
Fig.6-5: Adjusters and slider switches
Risk of actuator damage through opening the device.
Î Do not unscrew screws on the top housing cover.
Î Do not remove the top housing cover.
NOTICE
!
