Installation
5.5 Installing the resistance
transmitters
To install a resistance transmitter, the follow-
ingretrotpartsarerequireddependingon
the equipment:
− Basicunit:orderno.1690-1201
− Resistance transmitter 1:
order no. 1690-1204
− Resistance transmitter 2:
order no. 1690-1205
− Gearsegment:orderno.1690-1202
Î Installthebasicunit(seesection5.4).
1. Open the side housing cover.
2. Install the potentiometer into the potenti-
ometer carrier (5).
We recommend installing the potentiometer
into the potentiometer carrier before mount-
ing it.
The fastening of the resistance transmitter al-
so serves as a sliding clutch. Therefore, the
fastening nut must not be tightened too far
and must be secured with locking lacquer.
3. Plug the stranded wires on the contacts
of the potentiometer.
4. Secure the potentiometer carrier.
5. Slide the potentiometer pinion onto the
potentiometer.
6. Slide the segment gear onto the shaft (4).
Tip
Note
7. Adjust potentiometer as described in the
'Start-up' section.
8. Mount the locking spring of the potenti-
ometer.
9. Refasten the side housing cover.
5.6 Using the positioner as a
position transmitter
1. Disconnect the wires leading to the termi-
nals aL and eL.
Î Make sure that the disconnected wires
are properly insulated (e.g. by using in-
stallation clamps).
2. Wire the conductors of the external
three-step control signal (controller) to
the terminals aL, eL and 81.
The terminals 11, 12 and 13 as well as the
priority circuit at terminals 82 and 83 do not
function when a positioner is used as a posi-
tion transmitter.
Note
