EB 8340 EN 5-7
Installation
Limit contact 1, 2, 3
Terminal compartment with electric accessories
P1
Potentiometer 1
Motor electronics
Motor electronics and
positioner
P2
Potentiometer 2
Fig.5-4: Terminal compartment with the housing cover removed
