Start-up
The following functions can be adjusted with the slider switches SW1 to SW4:
Table7-1: Switch positions and their meaning
SW1 SW2 SW3 SW4
Priority operation for actuator stem retracts ON
Priority operation for actuator stem extends OFF
Directionofactionincreasing/decreasing(<>) ON
Directionofactionincreasing/increasing(>>) OFF
Positionfeedbacksignal4to20mA/2to10V ON ON
Positionfeedbacksignal0to20mA/0to10V OFF OFF
SW1:Prioritycircuit
The slider switch SW1isusedtosetthedirectionoftheprioritycircuittoincreasing/increas-
ing(>>)orincreasing/decreasing(<>).
SW2:Directionofaction
The slider switch SW2 is used to set the direction of action of the actuator.
SW3andSW4:Positionfeedbacksignal
The slider switches SW3 and SW4 are used to determine the position feedback signal.
The position feedback signal can be used for the following ranges:
− 4to20mAor2to10V
− 0to20mAor0to10V
