Design and principle of operation
Refertothefollowingdatasheetsfordimensionsandweights:
uT8097 for Type3347 Hygienic Angle Valve
uT8097-1 for Type3347/3372 Pneumatic Control Valve
Refer to the following data sheets as well as mounting and operating instructions for dimen-
sions and weights of the SAMSON pneumatic actuators:
uT8310-1 for Type3271 or Type3277 Pneumatic Actuators up to 750cm² actuator area
uT8313 for Type3372 Actuator
uEB8315 for Type3379 Actuator
Note
