9-10 EB 8097 EN
Servicing
3
25
26
25
Fig.9-8: DN25 to 100 · Cast body with PEEK
stem seal and centering ring
Fig.9-9: DN25 to 100 · Cast body with an-
ti-crystallizing stem seal system
3
13
21
Fig.9-10:DN25 to 80 · Cast body with PTFE
stem seal and steam barrier
