29 EB 8387-3 EN
Attachment to the control valve – Mounting parts and accessories
A
1
1.5 1.6
1.3 1.2 1.1 1 1.6
Z
A
2
1.4
A
1
A
2
Z
A
1
Output 38 Supply 9
Output 38 Supply 9
1.3 1.21.1
Fig. 10 · Mounting a reversing amplifier (1079-1118 or 1079-1119)
From the positioner
Control signals to
the actuator
1 Reversing amplifier
1.1 Special screws
1.2 Gasket
1.3 Special nuts
1.4 Rubber seal
1.5 Sealing plug
1.6 Filter
