Samson 3731-3 - 12 Dimensions in MM

12 Dimensions in mm
84 EB 8387-3 EN
Dimensions in mm
70
15
46
34
14
122
95
34
53
28
NPT ½, ¼
58
58
236
Output Supply
Fig. 16a · Attachment to IEC 60534-6 and direct attachment
Attachment acc. to
IEC 60534-6
→
Direct
attachment
→
Pressure
gauge
bracket
or connecting plate
(G ¼ only)
¼ NPT
Electrical connections:
2 x female thread
½ NPT or
M20 x 1.5
Lever in mm
S = 17
M = 50
L = 100
XL = 200
