Samson 3731-3 - Page 85

EB 8387-3 EN 85
Dimensions in mm
80
52
Output Y
1
Output Y
2
Supply (9)
Output Y
1
Output Y
2
56
86
130
80
166
30
86
Ø 101
Fig. 16b · Attachment to rotary actuators VDI/VDE 3845 (Sept. 2010), level 1, size AA1 to AA4
A
1
Z
A
2
56
86
130
80
166
30
86
Ø 101
76
50
Output A2
Output A1
Supply (9)
Type 3710
Reversing
Amplifier
Reversing amplifier
1079-1118 or
1079-1119
(option)
