13 Appendix
13.1 Selecting the valve characteristic
The characteristics that can be selected in Code 20 are shown in following in graph form.
Note: A characteristic can only be defined (user-defined characteristic) using a workstation/
operating software (e.g. TROVIS-VIEW).
Linear (select characteristic: 0)
Equal percentage (select characteristic: 1) Rev. equal percentage (select characteristic: 2)
EB 8387-3 EN 87
Appendix
0
50
100
0 50 100
Travel/ angle of rotation [%]
Reference variable [%]
0
50
100
0 50 100
Travel/ angle of rotation [%]
Reference variable [%]
0
50
100
0 50 100
Travel/ angle of rotation [%]
Reference variable [%]
