EB 8387-3 EN 33
Attachment to the control valve – Mounting parts and accessories
Table 4 · Attachment to rotary actuators (Figs. 8 and 9)
Order no.
Mounting
parts
Attachment acc. to VDI/VDE 3845 (September 2010), see section 12.1 for details
Actuator surface corresponds to level 1
Size AA1 to AA4, heavy-duty version
Size AA5, heavy-duty version (e.g. Air Torque 10 000)
1400-9244
1400-9542
Bracket surface corresponds to level 2, heavy-duty version 1400-9526
Attachment for SAMSON Type 3278 with 160 cm² and for VETEC Type S160, R and
M, heavy-duty version
1400-9245
Attachment for SAMSON Type 3278 with 320 cm² and for VETEC Type S320,
heavy-duty version
1400-5891
and
1400-9526
Attachment to Camflex II
1400-9120
Accessories
Connecting plate (6)
G
1
4
1400-7461
1
4
NPT 1400-7462
Pressure gauge bracket (7)
G
1
4
1400-7458
1
4
NPT 1400-7459
Pressure gauge mounting kit up to max. 6 bar (output/supply)
St. steel/brass 1402-0938
St. steel/st. steel 1402-0939
Table 5 · General accessories
Accessories
Pneumatic reversing amplifier for double-acting actuators Type 3710
Signal pressure restrictions (screw restriction (item no. 0390-1424) and brass restric-
tion (item no. 0390-1423))
1400-6964
TROVIS-VIEW with device-specific module for Type 3731-3 (refer to section 3.2.1)
Serial interface adapter (SAMSON SSP interface – RS-232 port on computer) 1400-7700
Isolated USB interface adapter (SAMSON SSP interface – USB port on computer)
including TROVIS-VIEW CD-ROM
1400-9740
